Laboratory of Materials Characterization

Laboratory of Materials Characterization
120 m2

Machines for Static and Dynamic Testing of Materials

MFL SYSTEME
PRÜF UND MESS

AXIAL TESTING MACHINE

CHARACTERISTICS

Force capacity: 250 kN
Actuator dynamic stroke: 100 mm
Max vertical test space: 750 mm
Grips depth: 60 mm

SPECIMEN TESTING

Specimen type: flat and round
Thickness: 0 mm to 25 mm
Diameter: 16 mm to 34 mm

COMPONENT TESTING

Take a look at video examples of specimen and component testing

Gallery

SCHENCK
HYDROPULS® PSA

AXIAL TESTING MACHINE

CHARACTERISTICS

Force capacity: 100 kN
Acuator dynamic stroke: 100 mm
Max vertical test space: 550 mm
Grips depth: 50 mm

SPECIMEN TESTING

Specimen type: flat and round
Thickness: 0 mm to 15 mm
Diameter: 8 mm to 17 mm

COMPONENT TESTING

Take a look at video examples of specimen and component testing

Gallery

MTS
858 Mini Bionix II

AXIAL TESTING MACHINE

CHARACTERISTICS

Force capacity: 15 kN
Actuator dynamic stroke: 100 mm
Max vertical test space: 450 mm
Grips depth: 35/38 mm

SPECIMEN TESTING

Specimen type: flat and round
Thickness: 0 mm to 7 mm
Diameter:
8.9 mm to 10.9 mm ( in case of specimen side installation)
8.9 mm to 15.2 mm (in case of specimen top installation)

COMPONENT TESTING

Take a look at video examples of specimen and component testing

Gallery

STEP LAB
EA05

AXIAL TESTING MACHINE

CHARACTERISTICS

Static force capacity: 5 kN
Dynamic force capacity: 3.5 kN
Actuator dynamic stroke: 200 mm

SPECIMEN TESTING

Specimen type: flat

COMPONENT TESTING

Take a look at video examples of specimen and component testing

Gallery

EnginLAB
Servo-pneumatic ASM Testing Machine

AXIAL TESTING MACHINE

CHARACTERISTICS

Static force capacity: 2.96 kN
Dynamic force capacity: 2.22 kN
Actuator dynamic stroke: 50 mm

SPECIMEN TESTING

Specimen type: flat

MFL SYSTEME
Torsional Testing Machine

CHARACTERISTICS
Torsional load capacity:
1100 Nm
Full rotation range: 120 degrees
Max test space: 2000 mm

METRO COM
Rotating Bending Machine

CHARACTERISTICS
Driven by an electric motor rotating at 12000 rpm
Load frequency: 200 Hz

Extensometers and Microscopes

Our collection of extensometers, digital microscopes and measure equipment

MTS Extensometer
Model 634.12F-24

Gage Length: 25 mm
Maximum Travel: –2.5 mm / +12.5 mm
Measuring Range (% Strain): -10% / +50%
Nominal Bridge Resistance: 350 Ohm

MTS Extensometer
Model 632.13F-20

Gage Length: 10 mm
Measuring Range (% Strain): -15% / +15%
Nominal Bridge Resistance: 350 Ohm

MTS Extensometer
Model 632.29F-30

Gage Length: 5 mm
Maximum Travel: –0.5 mm / +1.5 mm
Measuring Range (% Strain): -10% / +30%
Nominal Bridge Resistance: 1000 Ohm

MTS Clip-On Displacement Gage
Model 632.03F-30

Compressed Gage Length: 5 mm
Nominal Bridge Resistance: 350 Ohm

Dino-Lite Edge3.0 Digital Microscope
Model AM73915MZT

Type: Dino-Lite High Speed
Magnification
: 10-220x
Working distance: Standard
Sensor type: CMOS
Resolution: 5 Megapixel (2592×1944)
Max frame rate: 45fps (max 20fps for video recording)
Interface: USB 3.0
Included software: DinoCapture 2.0 (Windows)

Dino-Lite Edge Digital Microscope
Model AM4115ZT

Type: Dino-Lite Universal
Magnification
: 20-220x
Working distance: Standard
Sensor type: CMOS
Resolution: 1.3 Megapixel (1280×1024)
Max frame rate: 30fps
Interface: USB 2.0
Included software: DinoCapture 2.0 (Windows)

Dino-Lite Edge Digital Microscope
Model AM4115ZTL

Type: Dino-Lite Long Working Distance
Magnification
: 10-140x
Working distance: Long
Sensor type: CMOS
Resolution: 1.3 Megapixel (1280×1024)
Max frame rate: 30fps
Interface: USB 2.0
Included software: DinoCapture 2.0 (Windows)

Dino-Lite Edge Digital Microscope
Model AF4915ZT

Type: Dino-Lite Universal – Wired
Magnification
: 20-220x
Working distance: Standard
Sensor type: CMOS
Resolution: 1.3 Megapixel (1280×1024)
Max frame rate: 30fps
Interface: USB 2.0
Included software: DinoCapture 2.0 (Windows)
