Laboratory of Component Testing
180 m2
Hydraulic testing equipment
3 grooved restrain benches and 6 servo-hydraulic actuators
MTS 242 – 15 kN actuators
4 servo-hydraulic actuators, 15 kN each, 150 mm stroke
Italsigma – 10 kN actuators
2 servo-hydraulic actuators, 10 kN each
Pneumatic testing equipment
Modular test rig for light-vehicle chassis testing and 5 servo-pneumatic actuators
EnginLAB – 10 kN
2 servo-pneumatic actuators, 5 kN each, 100 mm stroke
EnginLAB – 5 kN
3 servo-pneumatic actuators, 10 kN each, 200 mm stroke
Devices for Crack Growth monitoring
3 Direct Current Potential Drop (DCPD) devices for crack initiation and crack growth monitoring
Matelect DCM-2 Option 5
2 potential drop channels + 1 temperature channel via external thermocouple input
Custom DCPD DAQ – 2 Channels
DOLI EDCi20
(2 potential drop channels + 1 temperature channel)
TDK-LAMBDA Genesys® GENH100-7.5
Current Generator
(Maximum direct current Imax = 100 A)
Custom DAQ Software: PDSoft DOPE
Custom DCPD DAQ unit – 7 Channels
DOLI EDCi70 (7 potential drop channels + 1 temperature channel)
TDK-LAMBDA Genesys® GENH100-7.5
Current Generator
(Maximum direct current Imax = 100 A)
Custom DAQ Software: PDSoft DOPE
Additional equipment
DAQ units for strain gages / accelerometers / potentiometers
2 x IMC CS-7008-FD, 8 channels
1 x IMC Cronos PL2, 8 channels, shippable
Telemetry system KMT 8 channels
Somat eDAQ, 24 channels, shippable
Agilent Technologies HP 34970
UPM 100, 40 channels, bench-top
Software for FE analyses
Ansys® Mechanical APDL
Ansys® Workbench/Mechanical
Altair® Hyperworks
Straus7®
Software for 3D fracture simulation: FRANC3D
Software for non-linear material & structure analysis: Z-Set
Software for 3D modelling: Dassault Systemes® Solidworks
Software for data analysis
MATLAB®
imc® FAMOS Enterprise
